Opis
Manufacturer color: black – Divisible: no – Pin length (side plug): 2.40 mm – Pin length (printed side): 3 mm – Socket depth: 5.80 mm – Industrial goods: no – Plug connector design: flat strip with female connectors – Contact surface: tinned – Contact material: copper alloy – Housing material: thermoplastic plastic – Length dimension: 10.00 mm – Height dimension: 2.54 mm – Width dimension: 10.00 mm – Rated voltage: 150 V/AC – Rated current: 3 A – Pin shape: round – Base grid: 2.54 mm – Pin diameter: 0.60 mm – Connection (components): for printed circuit board – Total number of poles: 40 – Directional plug: perpendicular to the printed circuit board – Temperature (max.): +125 C – Temperature (min.): -55 C – broj pozicija po redu: 40 – broj redova: 1
