Opis
The Fnirsi HS-01 is a smart portable soldering iron with an ergonomic design. This is a full set, including soldering iron, charger and 6 soldering tips. The HS-01 can be powered with USB-C PD 65W, in that case it will melt solder within 8 seconds from startup. Another way to power the HS-01 is with a 24V DC power adapter. With a power adapter the HS-01 has 96W of power.
The HS-01 has a metal housing and the tip is firmly secured in the soldering iron, unlike the TS101 and the Pinecil. Furthermore, a metal hood is included, so the soldering iron can be safely stored.
Specifications
| Power | 96 W DC / 65 W PD |
| Temperature range |
80 °C – 420 °C |
| Heating time |
~ 4 sec |
| Tip system | Active |
| Temperature stability | ± 2 % |
| Display | OLED |
| Automatic standby |
Yes, after 30 minutes
|
| Dimensions | 184 x 20 mm |
Accessories
The Fnirsi HS-01 soldering iron comes with:
- DC to USB type-C power cord
- 65W USB-C power supply
- Heat resistant USB-C charging cable
- Mini soldering iron stand
- HS-01-KR soldering tip (knife 4.66mm)
- HS-01-K65 soldering tip (knife 3.6mm)
- HS-01-B2 soldering tip (conical)
- HS-01-ILS soldering tip (conical, sharp tip)
- HS-01-BC3 soldering tip (bevel ⌀3mm)
- HS-01-BC2 soldering tip (bevel ⌀2mm)
