Opis
Digitalni termostat Enda EDP2041-230.
- Scale range: -1999 to 9999
- Power consumption 7 VA
- Accuracy ± 0.1 %
- Operating temperature 0 °C – 50 °C
- Connection: screw terminal strip for 2.5 mm²
- Resolution: output 1 mV or 2 µA
A digital potentiometer, with analogue process signal output 0-10V, 0 (4) 20 mA, freely adjustable scale range 1999 to 9999. Change the parameter value via buttons or via external input. Application, for example, the speed adjustment of a frequency converter. Safety code against unauthorized adjustment of the values set. Easy and intuitive operation using horizontal and vertical menu navigation, optionally with RS485 interface.
- Type
-
EDP2041-230
- Operating voltage
-
230V AC
- No. of analogue inputs
-
2
- Outputs
-
0-10V, 0 (4) -20 mA
- Dim
-
(L x W x H) 71 x 77 x 35 mm
- Factory colour
-
Black
- Height
-
35mm
- Length
-
71mm
- Width
-
77mm
- Manufacturer part #
-
EDP2041-230
- Recess depth
-
73mm
- Mounting type
-
Recess-mount
- Digital inputs
-
External Control
- Assembly dimensions
-
71 x 29.5mm
- Product type
-
Digital voltage divider
